Description

• Frequency Range: VHF: 136-174 MHz(Rx/Tx). UHF: 400-520 MHz(Rx/Tx)
• Brand Name: Baofeng
• Model Number: UV5R
• Storage Channel: Up to 128 channels
• Walkie Talkie Type: Portable
• Is_Display: Yes
• Material: Plastic
• Maximum Range: 5km-10km
• Dimensions: 58mm*110mm*32mm
• Talk Range: around 3-5km
• Walkie talkie quantity: 1pc (not a pair)
• Type: Two Way Radio

start

en

d















NOTICE:

Carefully unpack the transceiver. We recommend that you identify the items listed in the following before discarding the packing material.

If any items are missing or have been damaged during shipment, please contact us immediately.





UV-5R / Conventional parameter
General specification
frequency range	U/V: 400-520MHz/136-174MHz
channel capacity	128
Channel spacing	25.0kHz / 12.5kHz
Frequency stability	±1.5ppm
working temperature	-25℃ ~ +55℃
Antenna impedance	50Ω
working voltage	DC7.4V
Dimensions (L * w * h)	120×57×37mm
Weight (with battery and antenna)	241g
Battery	1600mAh (Lithium ion battery)
Acceptance specification
Receiving sensitivity	70dB / 60dB
Adjacent channel selectivity	65dB / 55dB
Intermodulation Rejection	55dB
Spurious Response	≥60dB
Signal to noise ratio	40dB / 35dB
Rated audio output power	≥900mW
Rated audio distortion	≤5%
Launch specifications
Transmitting power	UHF: 4W/1W  VHF: 5W/1W
modulation mode	16KΦF3E / 8KΦF3E
Modulation limit	≤5kHz / ±2.5kHz
FM distortion	≤5%
residual FM	-45dB / -40dB
Adjacent channel power	-70dB / -60dB
Stray and harmonic	≤-36dBm
